SANSIL 3D
Custom electronic enclosures – ABS, ASA, PC
Custom electronic enclosures — UV and weather resistance.
from €6.5 / piece
Enclosures & electronics
Flame-retardant enclosures and parts – UL94 V-0 rated materials
Flame-retardant enclosures and parts in PC-FR — a UL94 V-0 flame rating.
from €18 / piece
What it is for
- Protect a circuit board
- Fit a device into a harsh environment
- Produce a short run without tooling
When the specification says V-0, we print V-0: enclosures and technical parts in flame-retardant polycarbonate and PPS-CF, with material datasheets supplied for your file. One of the very few FDM workshops covering this niche — used for electrical, battery-adjacent and industrial control housings.
Cut-outs, cable routes and threaded inserts designed in from the start. PC-FR is specified here for a UL94 V-0 flame rating; another material remains possible depending on the real constraint on the part. Every order starts with a printability review: thin walls, overhangs and material shrinkage are flagged before production, not after.
Recommended materials
| PC-FR | Flame-retardant polycarbonate, UL94 V-0 rated, datasheet supplied. |
|---|---|
| PPS-CF | Up to 200 °C continuous. Quoted on request. |
Another material is possible: tell us the real constraint — temperature, UV, impact, contact — and we will propose one.
Specifications
| Recommended materials: PC-FR, PPS-CF |
| Part envelope up to 350 × 350 × 350 mm |
| Typical tolerance ±0.3 mm, ±0.15 mm on request |
| Support removal included, no other post-processing |
Frequently asked questions
Can I order a single part?
Yes. There is no minimum order: a one-off is handled exactly like a production run.
I don't have a 3D file — is that a problem?
No. A drawing, a dimensioned photograph or the original part is enough: we model it in Fusion 360 and hand over the STEP file as well.
Is the price shown a firm price?
It is an entry price. A firm quotation is issued within 24 working hours, based on your actual geometry and the quantity required.
